SOx Scrubber Systems
Complete emissions solutions
Following Wärtsilä's acquisition of Hamworthy we can now offer open loop, closed loop and hybrid systems to help you comply with existing air emissions regulations from the International Maritime Organisation (IMO), and the European Union who are working towards an alignment with IMO MARPOL Annex VI.
Managing fuel cost efficiency
Legislation has already had an effect on the fuel markets in regulated areas. Fuel prices are expected to increase even further in 2015 when the 0.1% fuel sulphur limit enters into force. Scrubbing technology is an economically and environmental friendly solution for tackling these requirements.
Scrubbers for all ship types
Wärtsilä's scrubbers are designed to provide flexibility and reliable operations wherever you operate. The systems are suitable for both new buildings and retrofitting of existing vessels having either 2-stroke or 4-stroke engines as well as oil-fired boilers. They can also provide complete ship design and a variety of pump systems.
Wärtsilä Open Loop Scrubber
Wärtsilä Open Loop Scrubber system benefits from Hamworthy's 50 year know-how. The system operates in an open loop, utilising seawater to remove SOX from the exhaust. Exhaust gas enters the scrubber and is sprayed with water in three different stages. The sulphur oxide in the exhaust reacts with water and forms sulphuric acid. There is no need for chemicals since the natural alkalinity of seawater neutralizes the acid. Wash water from the scrubber is treated and monitored at the inlet and outlet, to make sure it is in line with the discharge criteria of MEPC 184(59), before it is discharged to sea with no harm to the environment. Linea Messina has a Wärtsilä Open Loop Scrubber system installed, and was the first vessel ever to operate commercially with a scrubber system, enabling it to meet 0.1% sulphur emissions regulations in EU ports, as well as “futureproofing” the vessel for the impending 0.1% Emission Control Area limit in 2015.
Wärtsilä Closed Loop Scrubber
Wärtsilä Closed Loop Scrubber operates in a closed loop, i.e. the wash water is being circulated within the scrubber. Exhaust gas enters the scrubber and is sprayed with water that has been mixed with caustic soda (NaOH). The sulphur oxides in the exhaust react with this mixture and are thereby neutralized. A small bleed-off is extracted from the closed loop and treated to fulfil requirements stipulated by IMO. Cleaned effluents can safely be discharged overboard with no harm to the environment. If operation in zero discharge mode is requested, the effluent can be led to a holding tank for scheduled and periodical discharge.
A Hybrid Approach
In addition to Wärtsilä's Open and Closed Loop systems, Wärtsilä provides hybrid solutions. The hybrid approach enables operation in closed loop mode when required, for instance whilst in port and during maneuvering using NaOH as a buffer. When at sea the switch can be made to open loop using only seawater. Wilh. Wilhelmsen ASA, the global rolling cargo operator, will retrofit their vessel MV Tamesis with a Wärtsilä Hybrid System. The multi-stream scrubber system will remove sulphur and particulates and manage the exhaust gases produced by the
38,486 dwt Mark IV RoRo vessel’s combined engine power of 28,000 kW.
（译文参考：船舶管理部 机务培训师 傅恒星译）
SOX洗涤系统
完善的排放解决方案
Hamworthy和Wärtsilä并购后，我们现在提供开式循环，闭式循环及混合循环系统来帮助您满足当前的IMO相关大气排放控制规定，和满足欧盟一直致力于实现的与IMO MARPOL Annex VI相关规定的需求。
燃油的成本效率管理
立法已经对限制区域的燃油价格产生了影响。当2015年0.1%硫含量限制强制生效后，燃油价格预期会进一步走高。而废气洗涤技术是一种经济的、环境友好的可用来满足这些要求的解决方案。
适合与所有船型的洗涤技术
Wärtsilä洗涤塔被设计为使用揉性连接且工作可靠，可以提供在任何场合使用。该系统既适用于新造船同时也适用于现有的2-冲程或4-冲程柴油机，燃油锅炉同样适用。他们提供完整的船舶设计方案和各种配套泵浦。
Wärtsilä开式循环洗涤塔
Wärtsilä开式循环洗涤系统技术得益于Hamworthy50年的专业技术积累。该系统使用开式循环，利用海水除去废气中SOX。废气进入洗涤塔，在3个阶段与喷入的海水发生接触，废气中的SOX与水发生反应，生产硫酸。因为海水的碱性会自然中和废水中硫酸，因而无需后续化学处理。洗涤塔的进水和排水水质均被严格监控和处理，确保排放的水满足MEPC 184(59)的相关要求，且在排放入海前不会对环境造成危害。“Linea Messina”是第一艘安装该开式循环废气洗涤技术的船舶，能够满足欧盟港口0.1%硫含量的排放要求，而且正在进一步验证船舶能够满足2015年即将生效的控制区域（ECAs）排放要求。
Wärtsilä闭式循环洗涤塔
Wärtsilä闭式循环洗涤塔在闭式循环下运行，即清洗水在洗涤塔内部循环使用。废气进入洗涤塔与喷入混有NaOH的清洗水接触，废气中的SOX与之反应被中和。来自闭式循环的部分液体被分流并被处理至满足IMO排放标准。清洁后的废水不会对环境造成任何危害，可以安全的排放入海。如果要求进行零排放模式运行，可以将废水排至专用存储舱按计划和定期排放。
一种混合模式
Wärtsilä除提供开式和闭式循环系统外，还提供一种混合解决方案。当有特殊要求时使用闭式循环模式，例如在港期间和机动用车时，使用NaOH中和作为缓冲。在海上航行时切换到开式循环模式，仅仅使用海水中和。Wilh. Wilhelmsen ASA,全球滚装货物运营商，将在他们的MV Tamesis轮上加装混合式洗涤系统。这种多串流洗涤系统将会被用来处理这艘38486总吨的滚装船上总功率达28000KW的机器所产生的废气，除去其中的SOX和废气颗粒并且管理其废气系统。
